Specifications:
-
Brand: ArgoX
-
Model(s): HDES22
-
Length of CAT-6/CAT-5E cable between Rx and TX: Up to 60 meters
-
HDMI Input: 1080p/1080i/720p/576p/576i/480p/480i
-
HDMI Output: 1080p/1080i/720p/576p/576i/480p/480i
-
Max Bandwidth: 150MHz
-
Max Baud Rate: 4.5Gbps
-
Input Video Signal: 0.5~1.5Volts p-p
-
Output DDC Signal: 5Volts p-p (TTL)
-
Input HDMI Cable Distance: ≤10m AWG26 HDMI standard cable
-
Output HDMI Cable Distance: ≤15m AWG26 HDMI standard cable
-
TX Max Working Current: 350mA
-
RX Max Working Current: 200mA
-
Power Adapter Format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
-
Operating Temperature Range: (-15 to +45℃)
-
Operating Humidity Range: 5 to 90%RH (No Condensation)
-
Dimension (L x W x H): 59x56x17.5 (mm)
-
TX Weight: 50g
-
RX Weight: 48g
