Overview:
The Laney Digbeth DB-PRE is ideal for on-the-road portable bass playing, giving you the ability to produce high-quality sound wherever you go. It offers total control over incredible tones. One of its main functions is its ‘EQ Seesaw’ control. It has a central position and the ability to increase the overall mid to high frequencies and decrease the lows by turning it clockwise, opening your sounds to more presence, especially in a live performance. Turning the control anti-clockwise creates the opposite effect, decreasing the mid to high frequencies and increasing the lows which create a more resonant sound.
A necessity to the Laney Digbeth is FX Loops, which allows you to add effects between the input/output section on an amp. FX loops are important because they have additional effects on its distorted pre-amp section to produce various types of delay. FX loops allow you to put time-based effects after the distorted pre-amp section. The Laney Digbeth guarantees a noiseless switching system when operating with effects. Other features include a headphone socket, status LED, and high-quality switching components.
Specifications:
- Product: Bass Preamplifier
- Input Impedance (Passive): 1MΩ
- Input Impedance (Active): 100KΩ
- Output Link Impedance: 1KΩ
- Output Impedance: 1KΩ
- Aux Input: 3.5mm TRS Jack (4.7KΩ Input Impedance)
- Aux Phones: 3.5mm TRS Jack (100Ω Output Impedance)
- FX SEND: 6.35mm TS Jack -10dBV 1KΩ
- FX RETURN: 6.35mm TS Jack 22KΩ
- D.I. Output: XLR nominal -20dBV 680Ω
- Noise Level: (20 20KHz Filter) < 50µV
- Freq Response Bypassed: 20-20KHz (+/- 0.5dB)
- Rec Min Load Impedance: 10KΩ
- Power Supply: Regulated 9V DC PSU, center negative, 2.1x5.5x10mm connector type. (Not Included)
- Typical Current Consumption: 100mA
- Unit dimensions: (HWD) 57 x 145 x 122 mm
