Overview:
360 degree horizontal & vertical line for leveling, alignment and layout applications. Smart pendulum system allows tool to self-leveling, and it indicates out of level condition, Secure transport after switching off, pendulum is locked. Tripod thread: 1/4-IN-20 thread for use with positioning device or compact tripod. Three line selection models: projects line together or independently cross line, vertical and 360 degrees horizontal. Shockproof, waterproof and dustproof: you can wash it if the unit has dirt. New Green Diode technology is 300% as bright as red dots, I deal with bright conditions where red dots are hard to see.
Specifications:
- Brand: SNDWAY
- Model: SW-332R
- Laser Line Number: 8
- Laser color: Red
- IP Rating: IP54
- Operation Temperature Range: -10℃ – +50℃
- Storage Temperature Range: -20℃ – +70℃
- Power Supply: 4x1.5V AA
- Operating Time: Approximately 4-6 hours (with all laser beams on)
- Working Distance (Line with Detector): 50m
- Working Distance (Line): 20m (100)LUX
- Leveling/Compensation Range: 4°±1°
- Horizontal/Vertical Accuracy: ±3mm/10m
- Laser Wavelength: 635±5nm
- Laser lines: 8 lines
