SKU:SNDWAY SW-6310B

[CLEARANCE] Sndway SW-6310B Digital Paint Coating Thickness Meter Gauge Measuring Instrument with 2.0" LCD Display, Low Battery Notification, Auto Power Off Function

₱5,129.00
₱5,129.00 ₱7,358.00
Sale Sold out
Tax included. Shipping calculated at checkout.
View Product Details

Overview:

This coating thickness gauge is used to measure the thickness of plated and coated sheet metal, for example, paint/enamel/chrome on steel, paint and anodized coating on aluminum/copper. With the function of large LCD screen backlight and automatic detection of metal properties, this coating thickness tester is perfect for manufacturing company, metal machinery industry, chemical industry and commodity inspection, especially the car trade. 2.0 inch large segment screen, 180 degree flip screen for different viewing angles during the measurement process. Automatic detection of metal properties and display on the LCD screen, Fe symbol for magnetic substrate and NFe for non-magnetic substrate. Simple operation, glued directly to the coating and on the screen shows the property and thickness. Provides zero and multi-point calibration, calibrating reliably and quickly. When saving the measured data up to 30 sets, turning it off will not delete the data. Upper/lower limits warning function. Portable and streamlined shape design with special hand-held anti-slip treatment, lightweight, small size and fit for your palm. Widely used in the manufacturing industry, metal processing industry, chemical industry, commodity inspection area, and also capable of constantly working in the laboratory, workshop, and outdoors.



Specifications:
  • Brand: Sndway
  • Model: SW-6310B
  • Measuring range: 0-1700um
  • Display mode: Digital display
  • Material: ABS Plastic
  • Sensor Probe Type: Fe / NFe Working
  • Principle: Magnetic Induction (Fe) / Eddy Current (NFe)
  • Range: magnetic material 0 ~ 1700μm; non-magnetic material 0 ~ 1700μm
  • Units: μm, mil(1mil = 25.4μm, 1μm = 0.03937 mil)
  • Accuracy: ±(2 + 2% * H)μm @ (0 ~ 500μm), ±(2.5% * H)μm @ (500 ~ 1700μm)
  • Resolution: 0.1μm (0-99.9μm), 1μm(100-1700μm)
  • Minimum bending radius: convex 5mm, concave 30mm
  • Minimum measurement area: magnetic material 25 × 25mm; non-magnetic material 25 × 25mm
  • Minimum substrate thickness: magnetic 0.2mm, non-magnetic 0.05mm
  • Data storage: 30 groups
  • Display: 2.0-inch large segment display screen
  • Basic measurement: single/continuous measurement
