Key Features
- AX3000 dual-band Wi-Fi 6 access point
- Up to 574 Mbps on 2.4 GHz band
- Up to 2402 Mbps on 5 GHz band
- Centralized cloud and app management
Wall Mount
- Complete In-Room WiFi Coverage
- Multiple authentication options
- 802.3af/at PoE only
Ceiling Mount
- 160 MHz Channel
- Seamless Roaming
- Wireless Connectivity between AP for extended range
- 802.3at PoE+ / 12V DC
- Ultra-slim Design
Pole Mount
- IP68-rated weatherproof enclosure
- Supports mesh networking and PoE+ power
- 802.3at PoE+ / 48V Passive PoE
Specifications
- Brand: TP-LINK
- Wireless Standard: IEEE 802.11ax/ac/n/g/b/a
- Wi-Fi Class: AX3000
- Frequency: 2.4 GHz and 5 GHz
- Wireless Speed: 574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz)
- Wireless Features: OFDMA, MU-MIMO
Wall Mount
- Model: EAP650-Wall
- Product Type: Wall Plate Wi-Fi 6 Access Point
- Ethernet Port: 2× Gigabit Ethernet (1 Uplink, 1 Downlink)
- Power Supply: 802.3af/at PoE
- Antennas: 2× Dual-Band Antennas (2.4 GHz: 2× 3 dBi; 5 GHz: 2× 5 dBi)
- Mounting: Wall Plate Mounting
Ceiling Mount
- Model: EAP650
- Product Type: Ceiling Mount Wi-Fi 6 Access Point
- Ethernet Port: 1× Gigabit Ethernet (RJ-45)
- Power Supply: 802.3at PoE+ / 48V Passive PoE / 12V DC
- Antennas: Internal Omni (2.4 GHz: 2× 3 dBi; 5 GHz: 3× 5 dBi) — V2
- Mounting: Ceiling / Wall / Junction Box Mounting
Pole Mount
- Model: EAP650-Outdoor
- Product Type: Indoor/Outdoor Wi-Fi 6 Access Point
- Ethernet Port: 1× Gigabit Ethernet (RJ-45)
- Power Supply: 802.3at PoE+ / 48V Passive PoE
- Max. Power Consumption: 12.5W (EU) / 14.7W (US)
- Weatherproof Rating: IP68
- Antennas: 2× (2.4 GHz); 2× (5 GHz)
- Mounting: Pole / Wall Mounting
- Operating Temperature: -30°C to 70°C
- Operating Humidity: 10–90% RH, non-condensing
