● Support Output Editor: Patented decoding software, support a variety of special output format editing and customization, such as adding character identity, hidden output digits, display bar code system, etc.
● Excellent Decoding Performance: Gold-plated optical technology ,32 bits master chip equipped with proprietary software, smooth decoding barcodes which with reflective, folds, blur, color code even in light environment
● Barcodes Available: EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Code bar, industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, Chinese postal codes.
Specifications:
-
Performance
-
Scan Type: Laser
-
Decode Capacity: 1D
-
EAN8, EAN13, ISSN, ISBN, UPC-A, UPC- E, Code 39, Code 32, Code128, Code 93, Code bar, ITF5
-
-
Resolution: ≥3.9mil
-
Typical Decode Range
-
CODE 39 (3.9mil) 60mm-90mm (Barcode Size: 8mm*6mm)
-
CODE 39 (7.8mil) 90mm-210mm (Barcode Size: 106mm*6mm)
-
CODE 39 (17mil) 160mm-520mm (Barcode Size: 106mm*12mm)
-
CODE 39 (36mil) 200mm-1000mm (Barcode Size: 160mm*15mm)
-
EAN-13 (13mil) 60mm-320mm (Barcode Size: 31mm*16mm)
-
-
Print Contrast* ≥20%
-
Scan Angle** Skew+70°
-
Interface: USB
-
Dimension(mm): 165(W)x70(D)×90(H)(Max)
-
Voltage: 5VDC±5%
-
Power Consumption
-
Operating: 550mW
-
Standby: 350mW
-
-
Current@5 VDC
-
Operating: 110mA
-
Standby: 70mA
-
-
Operating Temperature: -10°C~+60°C
-
Storage Temperature: -40°C~+70°C
-
Humidity: 5%-95% (Non-Condensing)
|
|
