Specifications:
-
Brand: ArgoX
-
Model(s): HDES14 HDES15 HDES16 HDES17
-
Length of CAT-6/CAT-5E Cable Between Rx and TX: 60 meters / 120 meters
-
HDMI Input: 1080p/1080i/720p/576p/576i/480p/480i
-
HDMI Output: 1080p/1080i/720p/576p/576i/480p/480i
-
HDMI Input (HDES16 HDES17): 4k/1080p/720p/576p/576i/480p/480i
-
HDMI Input (HDES16 HDES17): 4k/1080p/720p/576p/576i/480p/480i
-
Max Bandwidth: 150MHz
-
Max Bandwidth(HDES16 HDES17): 340MHz
-
Max Baud Rate: 4.5Gbps
-
Max Baud Rate(HDES16 HDES17): 3x3.4Gbps
-
Input Video Signal: 0.5~1.5Volts p-p
-
Output DDC Signal: 5Volts p-p (TTL)
-
Input HDMI Cable Distance: ≤10m AWG26 HDMI standard cable
-
Output HDMI Cable Distance: ≤15m AWG26 HDMI standard cable
-
TX Max Working Current: 300mA
-
TX Max Working Current(HDES16 HDES17): 500mA
-
RX Max Working Current: 300mA
-
Power Adapter Format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
-
Operating Temperature Range: (-15 to +45℃)
-
Operating Humidity Range: 5 to 90%RH (No Condensation)
-
Dimension (L x W x H): 60x56x19 (mm) / 64x59x22(mm)
-
TX Weight: 53g
-
RX Weight: 53g
