Features:
- Support HDMI 2.0b version
- Support 3D video format
- Support high resolution up to 3840X2160/60HZ
- Support highest rate of 6G and TMDS clock can be up to 600 MHz
- Support 8/10/12 bit deep color
- Support AWG26 HDMI standard cable: input up to 15 meters, output up to 20 meters.(resolution 1080P,4K/30Hz)
- Support AWG26 HDMI standard cable: input up to 5 meters, output up to 5 meters(resolution 4K/60HZ)
- Support one single HDMI source, accessing to multiple HDMI sinks, the source can be DVD player, A/V receiver, set top box and etc.
- 5V/1A power adapter
Specifications:
- Brand: ArgoX
- Model(s): HDSP2-V2.0 / HDSP4-V2.0 / HDSP8-V2.0 / HDSP10-V2.0 / HDSP16-V2.0
- HDMI version: HDMI2.0b
- HDMI resolution: up to 3840*2160/60Hz
- Support video format: 8/10/12 bit deep color
- Support audio format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
- Max bandwidth: 600MHZ
- Max baud rate: 6Gbps
- HDMI Input (HDSP2-V2.0) (HDSP4-V2.0) (HDSP8-V2.0) (HDSP10-V2.0) (HDSP16-V2.0): 1
- HDMI Output (HDSP2-V2.0): 2
- HDMI Output (HDSP4-V2.0): 4
- HDMI Output (HDSP8-V2.0): 8
- HDMI Output (HDSP10-V2.0): 10
- HDMI Output (HDSP16-V2.0): 16
- Input cable distance: (1080p,4K/30Hz resolution)≤15m, (4K 60hz resolution)≤5m AWG26 HDMI standard cable
- Output cable distance: (1080p,4K/30Hz resolution)≤20m, (4K 60hz resolution)≤5m AWG26 HDMI standard cable
- Input cable distance (HDSP8-V2.0): (1080p,4K/30Hz resolution) ≤15m, (4K 60hz resolution) ≤5m AWG26 HDMI standard cable
- Output cable distance (HDSP8-V2.0): (1080p,4K/30Hz resolution) ≤20m, (4K 60hz resolution) ≤5m AWG26 HDMI standard cable
- Input cable distance (HDSP10-V2.0): ≤5m AWG26 HDMI standard cable
- Output cable distance (HDSP10-V2.0): ≤10m AWG26
- Input cable distance (HDSP16-V2.0): (1080p,4K/30Hz resolution) ≤10m, (4K 60hz resolution) ≤5m AWG26 HDMI standard cable
- Output cable distance (HDSP16-V2.0): (1080p,4K/30Hz resolution) ≤15m, (4K 60hz resolution) ≤10m AWG26 HDMI standard cable
- Max working current: 440mA, 650mA, 1.6mA, 1.4mA, 1.15mA
- Power adapter format: input AC(50Hz, 60Hz)100V-240V; DC5V/1A
- Operating temperature range: (-15 to +55℃)
