Features:
- Support HDMI 1.4b Version
- Support Full 3D Video Format
- Support HDMI resolution up to 3840x2160/30Hz
- Support the Max Baud Rate of 3.4G and Max Bandwidth of 340Mhz
- Support deep color 8/10/12 bit deep color
- Support input up to 8 metres AWG26 HDMI standard cable length, output up to 8 metres AWG26 HDMI standard cable length
- Displaying single source, multi-output high-definition signal source from DVD player A/V receiver, set-top box
- 5V/1A power adapter
Specifications:
- Brand: ArgoX
- Model(s): HDSP2 / HDSP4 / HDSP8
- HDMI Version: HDMI 1.4b
- HDMI Resolution: up to 3840 x 2160/30Hz
- Support Video Format: 8/10/12bit Deep color
- Support Audio Format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
- Max Bandwidth: 340MHz
- Max Baud Rate: 3.4Gbps / 3.2Gbps
- Input Cable Distance (HDSP2): ≤8m AWG26 HDMI Standard Cable
- Output Cable Distance (HDSP2): ≤8m AWG26 HDMI Standard Cable
- Input Cable Distance (HDSP4): (1080p resolution) ≤15m, (4K resolution) ≤12m AWG26 HDMI Standard Cable
- Output Cable Distance (HDSP4): (1080p resolution) ≤25m, (4K resolution)≤15m AWG26 HDMI Standard Cable
- Input cable distance (HDSP8):(1080p resolution) ≤10m,(4K resolution) ≤5m AWG26 HDMI standard cable
- Output cable distance (HDSP8): (1080p resolution) ≤20m,(4K resolution) ≤10m AWG26 HDMI standard cable
- HDMI Input: 1 HDMI
- HDMI Output: 2 HDMI
- Max Working Current: 500mA / 1.58A
- Specifications of Power Adapter: input AC (50Hz, 60Hz) 100V-240V; output: DC5V/1A
- Operating Temperature Range: (-15℃to +55℃)
- Operating Humidity Range: 5 to 90%RH (No Condensation)
- Dimension (L x W x H): 128x53x23.5 (mm) / 178x67x23 (mm) / 276x136x24 (mm)
- Weight: 139g / 230g / 660g
