Features:
-
Support 4 HDMI inputs, 1 HDMI output;
-
Support 3D;
-
Support highest video resolution 4K/60Hz;
-
Support 18Gbps data rate for tmds clock up to 600MHz;
-
Support 24/30/36 bit deep color;
-
Can automatically switch HDMI input port (in 4 ports, the last one is priority);
-
Support USB 2.0;
-
Support 4 USB host (PC), 2 USB device (mouse/keyboard/U disk);
-
Support wireless mouse and keyboard;
-
Support Windows, Linux, MAC OS and Android operation system, etc;
-
Plug and play, no need to install any driving program;
Specifications:
-
Brand: ArgoX
-
Model: HDSW4-KVM-V2.0
-
HDMI Resolution: 4K/60Hz or 4K/30Hz
-
USB Rate: Low Speed(1.5Mb/s); Full Speed(12Mb/s); High Speed(480Mb/s)
-
USB Version: Compatible with USB 2.0 Full / Low speed
-
Support Video Format: 3D
-
Support Video Color Format: 24 / 30 / 36 Bit Deep Color
-
Support Audio Format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
-
Max Bandwidth: 600MHz
-
Max Baud Rate: 6 x 3Gbps
-
Input Cable Distance: ≤5m AWG26 HDMI standard cable;
-
Output Cable Distance: ≤5m AWG26 HDMI standard cable;
-
USB Cable Length: Standard USB 2.0 cable ≤ 2m
-
Power Adapter Format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
-
Max Working Current: 500mA
-
Operating Temperature Range: (-10 to +55℃)
-
Dimension (L x W x H): Approx. 177 x 58 x 20 (mm)
-
Weight: Approx. 210g
What's in the Box:
-
KVM HDMI Switch 4x1
-
IF Remote Control
-
USB 2.0 Type A Male Cable
-
User Manual
-
5v Power Adapter
