Features:
- Support 6Gbps data rate for tmds clock up to 600MHz
- Support HDMI2.0b
- Support 3D
- Supports highest video resolution 4K/60Hz
- Support HDR
- Support 24/30/36 bit deep color
- Supports auto switch of HDMI input (priority of the last port in 4) (For HDSW4-V2.0)
- Support AWG26 HDMI standard cable,Input up to 8metres ,output up to 8metres (4K/30Hz
- resolution and below)
- Support 2.0 HDMI standard cable, input up to 3 meters, output up to 5 meters (4K/60Hz
- resolution)
- Supports single high definition display for multiple sources, such as DVD Players, PS4
- and HD players, Set Top Boxes
- Needs 5V/1A power adapter.
Specifications:
- Brand: ArgoX
- Model(s): HDSW3-V2.0 / HDSW4-V2.0 / HDSW3X1 / HDSW4X1
- HDMI Version: HDMI 2.0b
- No. of Ports:
- HDSW3-V2.0: 3
- HDSW4-V2.0: 4
- HDSW3X1: 3
- HDSW4X1: 4
- HDMI Resolution: Up to 4K/60Hz
- Support Video Format: 3D
- Support Video Color Format: 24/30/36 bit deep color
- Support Audio Format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
- Max Bandwidth: 600MHz
- Max Baud Rate: 6Gbps
- Input Cable Distance: ≤8m AWG26 HDMI standard cable under 4K/30Hz; ≤3m 2.0 HDMI standard cable in 4K/60Hz
- Output Cable Distance: ≤8m AWG26 HDMI standard cable in 4K/30Hz; ≤5m 2.0 HDMI standard cable in 4K/60Hz
- Max Working Current: 350mA /250mA
- Operating Temperature Range: (-10 to +55℃)
- Power Adapter Specification: AC (50HZ, 60HZ)
- 100V-240V; Output: DC5V/1A
- Dimension (L x W x H): 102x79x22 (mm) / 136x80x22 (mm) / 122x56x15 (mm)
- Weight: 90g / 118g / 65g / 80G
