Features:
-
Support HDCP1.4;
-
Very compact structure;
-
Stable and reliable;
-
Via HDMI out1, support 3.5mm earphone jack and optical output at same time;
-
Economical and cost-effective;
-
Support 3D；
-
Support IR Remote Control；
-
Support RS232 Control;
-
The four outputs could show the same or different source simultaneously;
Specifications:
-
Brand: ArgoX
-
Model(s): HDMX03-V1.4 / HDMX03-V2.0
-
HDMI Resolution: up to 4K/30Hz / up to 4K/60Hz
-
Support Video Format: 8/10/12 bit deep color
-
Support Audio Format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
-
Max baud rate: 3x3.4Gbps / 18Gbps
-
Input Cable Distance: 4K/30Hz ≤15M AWG26 HDMI standard cable / 4K/60Hz ≤15M HDMI 2.0 standard cable
-
Output Cable Distance: 4K/30Hz ≤15M AWG26 HDMI standard cable / 4K/60Hz ≤15M HDMI 2.0 standard cable
-
HDMI Input: 4
-
HDMI Output: 4
-
Max Working Current: 0.6A / 0.8A
-
Power Adapter Format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC12V/1A
-
Operating Temperature Range: (-15 to +45℃)
-
Operating Humidity Range: 5 to 90%RH (No Condensation)
-
Dimension (L x W x H): 276x143x26 (mm)
-
Weight: 720g
What's in the Box:
-
HDMX03-V1.4 HDMI MATRIX
-
HDMX03-V2.0 HDMI MATRIX
-
IR Remote Control
-
12V Power Adapter
-
User Manual
