Specifications:
-
Brand: ArgoX
-
Model(s): HDES02-C / HDES60-V2.0
-
Length of CAT-5E/CAT-6 cable between Rx and TX: up to 120 meters / 60 meters
-
HDMI input: 4K/1080p/720p/576p/576i/480p/480i
-
Support audio format: DTS/Dolby/LPCM
-
HDMI output: 4K/1080p/720p/576p/576i/480p/480i
-
Max bandwidth: 340MHz / 600MHz
-
Max baud rate: 3.4Gbpsx3 / 6Gbps x3
-
Input video signal: 0.5~1.5Volts p-p
-
Output DDC signal: 5Volts p-p (TTL)
-
Input HDMI cable distance: ≤15m AWG26 HDMI standard cable
-
Output HDMI cable distance: ≤15m AWG26 HDMI standard cable
-
Input HDMI cable distance (HDES60-V2.0): ≤10m AWG26 HDMI standard cable
-
Output HDMI cable distance (HDES60-V2.0): ≤10m AWG26 HDMI standardcable
-
TX Max working current: 350mA
-
RX Max working current: 200mA
-
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
-
Operating Temperature range: (-15 to +55℃)
-
Operating Humidity range: 5% to 90%RH (No Condensation)
-
Dimension (L x W x H): 94x84x24(mm)
-
TX Weight: 223g
-
RX Weight: 223g
