Specifications:
-
Brand: ArgoX
-
Model(s): HDES100-A
-
Length of CAT5e/CAT6 cable between Rx and TX: Up to 100 meters
-
HDMI Input: 4k/1080p/720p/576p/576i/480p/480i
-
HDMI Output: 4k/1080p/1080i/720p/576p/576i/480p/480i
-
Max bandwidth: 340MHz
-
Max baud rate: 3x3.4Gbps
-
Input video signal: 0.5~1.5Volts p-p
-
Output DDC signal: 5Volts p-p (TTL)
-
Input HDMI cable distance: ≤15m AWG26 HDMI standard cable
-
Output HDMI cable distance: ≤15m AWG26 HDMI standard cable
-
TX Max working current: 350mA
-
RX Max working current: 200mA
-
Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
-
Operating Temperature range: (-15 to +55℃)
-
Operating Humidity range: 5 to 90%RH (No Condensation)
-
Dimension (L x W x H): 82x45x18 (mm)
-
TX Weight: 100g
-
RX Weight: 120g
