Features:
-
Support HDMI 1.4b.
-
Support local loop-out .
-
Support 100m long distance transmission
-
Low power consumption, low temperature and high safety.
-
Support 3D video format
-
Both the TX and RX support 3.5MM left and right audio output
-
Support IR control
Specifications:
- Brand: ArgoX
- Model(s): HDES100-P
- Length of CAT5e/CAT6 cable between Rx and TX: Up to 100 meters
- HDMI Input: 4k/1080p/720p/576p/576i/480p/480i
- HDMI Output: 4k/1080p/1080i/720p/576p/576i/480p/480i
- Max Bandwidth: 340MHz
- Max Baud Rate: 3x3.4Gbps
- Input Video Signal: 0.5~1.5Volts p-p
- Output DDC Signal: 5Volts p-p (TTL)
- Input HDMI Cable Distance: ≤15m AWG26 HDMI standard cable
- Output HDMI Cable Distance: ≤15m AWG26 HDMI standard cable
- TX Max Working Current: 350mA
- RX Max Working Current: 200mA
- Power Adapter Format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
- Operating Temperature Range: (-15 to +55℃)
- Operating Humidity Range: 5 to 90%RH (No Condensation)
- Dimension (L x W x H): 81 x 87.5 x 23.5 (mm)
- TX Weight: 210g
- RX Weight: 200g
