Specifications:
-
Brand: ArgoX
-
Model: HDES18
-
Length of CAT-5E/6 Cable between RX and TX: 60 Meters
-
HDMI Input: 1080p/1080i/720p/576p/576i/480p/480i
-
HDMI Output: 1080p/1080i/720p/576p/576i/480p/480i
-
Max Bandwidth: 150MHz
-
Max Baud Rate: 4.5Gbps
-
Input Video Signal: 0.5 ~ 1.5Volts p-p
-
output DDC Signal: 5Volts p-p (TTL)
-
Intput HDMI Cable Distance: ≤10m AWG26 HDMI Standard Cable
-
Output HDMI Cable Distance: ≤15m AWG26 HDMI Standard Cable
-
TX Max Working Current: 300mA
-
RX Max Working Current: 300mA
-
Power Adapter Format: Input: AC (50Hz, 60Hz) 100V - 240V; Output: DC 5V/1A
-
Operating Temperature Range: (-15 to +45°C)
-
Operating Humidity Range: 5 to 90%RH (No Condensation)
-
Dimension (LxWxH): 94x84x24(mm)
-
TX Weight: 220g
-
RX Weight: 220g
