Features:
-
Support 3D video format
-
Support for 4K (input) resolution 2K (output)（Down scaler）
-
Support 2 HDMI audio outputs, 3.5mm earphone jack and optical output at same time
-
6 HDMI inputs switch and split to 2 HDMI displays.
-
Support LPCM/Dolby/DTS 5.1 channel.
Specifications:
-
Brand: ArgoX
-
Model(s): HDMX01
-
HDMI Resolution: up to 3840*2160/60Hz
-
Support Video Format: 8/10/12 bit deep color
-
Support Audio Format: LPCM/DTS/Dolby-AC3
-
Max Bandwidth: 600MHz
-
Max Baud Rate: 3x6Gbps
-
Input Cable Distance: 4K/30Hz ≤15M AWG26 HDMI standard cable / 4K/60Hz ≤5M HDMI 2.0 standard cable
-
Output Cable Distance: 4K/30Hz ≤15M AWG26 HDMI standard cable / 4K/60Hz ≤5M HDMI 2.0 standard cable
-
HDMI Input: 6
-
HDMI Output: 2
-
Max Working Current: 1A
-
Power Adapter Format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1.5A
-
Operating Temperature Range: (-15 to +45℃)
-
Operating Humidity Range: 5 to 90%RH (No Condensation)
-
Dimension (L x W x H): 200x70x25 (mm)
-
Weight: 305g
