Features:
-
Support 4 HDMI inputs, 1 HDMI output;
-
Support 4 channels HDMI signal screen segmentation;
-
Support Highest Resolution up to 4K@30Hz;
-
Support Resolution 4K,1080P,720P,1024X768,1360X768,etc;
-
Support IR Control;
-
Support Audio Output Format: PCM;
-
Supports 1 way Mouse and Keyboard to Control 4 ways PC host;
-
USB Supports Windows/Linux/MAC OS and Android Operation System, etc;
-
Plug and Play;
-
Support USB 1.1 Low Speed(1.5Mb/s); Full Speed(12Mb/s);
Specifications:
-
Brand: ArgoX
-
Model(s): HDSW4-V
-
HDMI Resolution: 4K/30Hz
-
Audio Format: PCM
-
Input Cable Distance: 4K/30Hz ≤10M AWG26 HDMI standard cable
-
Output Cable Distance: 4K/30Hz ≤10M AWG26 HDMI standard cable
-
Max Bandwidth: 340MHz
-
Max Baud Rate: 3.4x3Gbps
-
Maximum Working Current: 400 mA
-
Power Adapter Format: Input AC (50 hz, 60 hz) 100V to 240V; Output: DC 12V 1A
-
Operating Temperature Range: (-10 ~ + 45 ℃)
-
Dimension: 256x153x35(mm)
-
Weight: 1.2Kg
