Features:
-
Support 4 HDMI inputs, 1 HDMI output;
-
Support 4 channels HDMI signal screen segmentation;
-
Support input highest resolution up to 4K/30Hz;
-
Support Output resolution 4K@60Hz, 4K@30Hz, 1080P@60Hz, 2560x1600@60Hz;
-
Support IR control;
-
Support audio output format: PCM2.0;
-
Support 24/30/36 bit deep color;
-
Support standard AWG26 cable, input up to 15 metres ,output up to 15 metres;
-
Supports 1 way mouse and keyboard to control 4 ways PC host;
-
USB supports Windows、Linux、 MAC OS and Android operation system,etc;
-
Plug and play;
-
Supports USB 2.0 Low speed(1.5Mb/s); Full speed(12Mb/s);
Specifications:
- Brand: ArgoX
- Model(s):HDSW4-V1
- HDCP version: HDCP 1.4
- Color format: RGB 4:4:4; YUV 4:4:4; YUV 4:2:2
- Audio format: Stereo
- Max bandwidth: 600MHz
- Max baud rate: 6x3Gbps
- Maximum working current: 0.8 A
- Power adapter format: Input AC (50 hz, 60 hz) 100V to 240V; Output: 12V DC
- Operating Temperature range: (10 ~ + 45 ℃)
- Dimension: 258x154x37(mm)
- Weight: 1239g
