KVM HDMI EXTENDER
Transmitter to 4x Receiver
KVM HDMI extender 1x4 uses the standard TCP/IP protocol, it can be divided into 4 network cable outputs, replaced the switch connection, to achieve one-to-many video connection function. It can be connected DVD player or computer device which is HDMI high definition video, using the cat5e/6 network cable to transmit up to 200m distance. It is convenient to transmit HDMI audio and video source by one to four.
Features:
- Support MJPEG decoding;
- Support HDCP1.4;
- Support 802.3 Ethernet standard;
- Replace the switch, to achieve one to four functions;
- Support switch connection;
- Support for infrared extension;
- Support USB mouse and keyboard extension.
- The design of pure hardware, plug and play, no need for additional software.
Specifications:
Video Resolution 480P, 720P, 1080P
Support Video Format RGB，YCbCr444，YCbCr422
Support Audio Format Stereo:32kHz,44.1kHz and 48kHz
Max Bandwidth 148.5MHz
Max Transmission Rate 1.5Gbps
Input Cable Distance AWG26 HDMI standard cable up to 15 meters
Power Adapter Format AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A
Max Working Current 0.8A
Dimension (L x W x H) 121x112x19mm
Weight 220g
Operating/Temperature/Humidity 0℃-45℃/10%-80%RH(no condensation)
Storage Temperature/Humidity -10℃-70℃/5%-90%RH(no condensation)
What's inside the box?
1x KVM HDMI Extender
1x Power Adapter 5V
1x USB Cable Male to male
1x IR Cable
1x User Manual
1x Receiver
