Description:
General:
VHF 144-148MHz & UHF 420-450MHz
Memory channels Up to 128 channels
Frequency stability 2.5ppm.
Frequency step 2.5kHz/5kHz/6.25kHz/10kHz/12.5kHz/20/kHz/25kHz.
Antenna impedance 50Ω.
Operating temperature -20℃to +60℃
Supply voltage Rechargeable Lithium-Ion mAh 7.4V/1800.
Consumption in reception 380mA
Consumption in transmission ≤1.4 A.
Mode of operation Simplex or semi-duplex.
Duty cycle 03/03/54 min. (Rx / Tx / Standby).
Dimensions 58mm x 110mm x 32mm
Weight 130 g (approximate).
Features:
- Frequency range: 136-174/400-480MHz
- Channel capacity: 16
- Frequency stability: ±2.5ppm
- working temperature: -20℃ ~ +60℃
- Antenna impedance: 50Ω
- Mode of Operation: Simplex
- Supply Voltage: 7.4V/1800
- Dimensions (L * w * h): 58mm x 110mm x 32mm
- Weight (with battery and antenna): 130g
- Battery: 2800mAh (Lithium ion battery)
- Receiving sensitivity: 0.2 V(12dB SINAD)
- Intermodulation: 60dB RF Power: <5W /1W
- Maximum deviation(W/N): 5KH/2.5KHz
- Spurious emission: <-60dB
- Adjacent channel power: -65dB/60dB
- SNR(W/N): 45dB/40dB
- QT/DQT(W/N): 0.7+0.1KHz/0.4+0.1KHz
- Modulation sensitivity: 8-12mV
- Audio Output: 1W
- Adjacent channel selectivity(W/N): 65dB/60dB
- Clutter supression: 65dB
- Receiver current: 380mA
- No FM Radio
Package Inclusions:
BaoFeng UV-82 / headset / 1800mAh Battery / Antenna / Power Adapter / Belt Clip / Hand Strap / Battery Charger / User Manual
