Description:
General:
VHF 144-148MHz & UHF 420-450MHz
Memory channels Up to 128 channels
Frequency stability 2.5ppm.
Frequency step 2.5kHz/5kHz/6.25kHz/10kHz/12.5kHz/20/kHz/25kHz.
Antenna impedance 50Ω.
Operating temperature -20℃to +60℃
Supply voltage Rechargeable Lithium-Ion mAh 7.4V/1800.
Consumption in reception 380mA
Consumption in transmission ≤1.4 A.
Mode of operation Simplex or semi-duplex.
Duty cycle 03/03/54 min. (Rx / Tx / Standby).
Dimensions 58mm x 110mm x 32mm
Weight 130 g (approximate).
Features:
-
Frequency range: 136-174/400-480MHz
-
Channel capacity: 16
-
Frequency stability: ±2.5ppm
-
working temperature: -20℃ ~ +60℃
-
Antenna impedance: 50Ω
-
Mode of Operation: Simplex
-
Supply Voltage: 7.4V/1800
-
Dimensions (L * w * h): 58mm x 110mm x 32mm
-
Weight (with battery and antenna): 130g
-
Battery: 2800mAh (Lithium ion battery)
-
Receiving sensitivity: 0.2 V(12dB SINAD)
-
Intermodulation: 60dB RF Power: <5W /1W
-
Maximum deviation(W/N): 5KH/2.5KHz
-
Spurious emission: <-60dB
-
Adjacent channel power: -65dB/60dB
-
SNR(W/N): 45dB/40dB
-
QT/DQT(W/N): 0.7+0.1KHz/0.4+0.1KHz
-
Modulation sensitivity: 8-12mV
-
Audio Output: 1W
-
Adjacent channel selectivity(W/N): 65dB/60dB
-
Clutter supression: 65dB
-
Receiver current: 380mA
-
No FM Radio
