Description:
High-Current toroidal Transformer
Independent Level Control Per Channel
Dual Variable Speed Fans
Independent Stereo, Parallel, Bridge Input
bypass/LPF(120Hz) mode
Ground/Lift Switch
BalanceXLR Input&Output(Thru)
Speakon and Binding Post Speaker output
All Stell 4URcarack,chasis
Features:
- Stereo Power 8ohms: 2 x 3000W
- Stereo Power 4ohms: 2 x 5000W
- Stereo Power 2ohms: 2 x 7000W
- Bridge Mono Power 8ohms: 8000W
- Bridge Mono Power 4ohms: 10000W
- Ratio: 105dB
- Slew Rate>10V/us
- Damping Factor: 900:1
- Frequency Response: 0.1 dB, 20Hz-20KHz
- TotalHarmonic Distortion: <0.5% Rated Power@ 8 ohms 1KHz
- Input Sensitivity: 0.775, 1.0, 1.44V (Selectable)
- Input Impedance: 20Kohms Balance or 10Kohms Unbalance
- LED Indicator: Clip,Signal, Protect, Power
- Class: Class H
- Type: Balance: XLR Input and Output
- Power Supply & Fuse: 220V/ 50-60Hz T60A
- DIMENSION: L73 XW52 X H24
- WEIGHT: 58.4 KG
-
