LogicOwl OJ-WM3 2.4G Wireless USB 1D,2D and QR Barcode Scanner Portable Handheld CCD Screen Payment QR Code Reader
LogicOwl OJ-WM3 2.4G Wireless USB 1D,2D and QR Barcode Scanner Portable Handheld CCD Screen Payment QR Code Reader
Specification:
Sensor Resolution |
960*640 |
||
Capacity |
1D(EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codebar,industrial 2 of 5,Interleave 2 of 5,Matrix 2 of5,MSI,etc); 2D(PDF417,MICROPDF417,Datamxtrix,QR,Maxicode,Aztec,etc) |
||
Depth of Field |
Tested Code |
Minimum |
Maximum |
5mil code39 |
1.5cm |
8cm |
|
13mil EAN13 |
4cm |
23cm |
|
15mil DM |
3cm |
14cm |
|
15mil QR |
2cm |
13cm |
|
15mil PDF417 |
6cm |
18cm |
|
Light Source |
Wavelength,675nm±3nm Infrared LED |
||
Decode Accuracy |
3mil |
||
Code Available |
1D,2D Codes printing on Paper or film on Cellphone |
||
Scanning Speed |
230 Times/Second |
||
Symbol Contrast |
20% |
||
Scanning Angle |
Horizontal : 72° Vertical:82° Rotated:360° |
||
Transmission range |
The open space 25 meters |
||
Wireless Technology |
2.4G |
||
Wireless transmit power |
7dBM |
||
Wireless receiver sensitivity |
-42dBM |
||
Drop |
Design to withstand 1.5 M drops to concrete 300 TIMES |
||
Environmental Sealing |
IP54 |
||
Working Temperature |
-20-55 Celsius degree |
||
Conserve Temperature |
-40-65 Celsius degree |
||
Working/Conserve Humidity |
5-95% Non-Condensed |
||
Environment Light |
0-120000LUX |
||
Net Weight |
145g |
||
Packing Weight |
330g |
||
Host Size(L*W*H) |
167mm* 72mm*85mm |
||
Packing Size(L*W*H) |
185mm*110mm*80mm |
||
Prompting |
Buzzer, Red & Blue LED |
||
Battery capacity |
2000MAH |
||
Maximum Current |
373MA |
||
Working Current |
168MA |
||
Standby Current |
72MA |
