- Specifications Detail
General Feature
- Application: Client PCs
- Rated Capacity: 250GB, 500GB, 1TB
- Form Factor: M.2 (2280)
- Interface: PCIe Gen 3.0 x 4, NVMe 1.3
- Dimension (WxHxD): 80.15 x 22.15 x 2.38 (mm)
- Weight: Max 8.0 g Weight
- Storage Memory: Samsung V-NAND 3-bit MLC
- Controller: Samsung Phoenix Controller
- Cache Memory: Samsung 1GB Low Power DDR4 SDRAM
Special Feature
- TRIM Support: Supported
- S.M.A.R.T Support: Supported
- GC (Garbage Collection): Auto Garbage Collection Algorithm
- Encryption Support: AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
- WWN Support: Not supported
- Device Sleep Mode Support: Yes
Performance
- Sequential Read: Up to 3,500 MB/s
- Sequential Write: Up to 3,300 MB/s
- Random Read (4KB, QD32): Up to 600,000 IOPS
- Random Write (4KB, QD32): Up to 550,000 IOPS
- Random Read (4KB, QD1): Up to 19,000 IOPS
- Random Write (4KB, QD1): Up to 60,000 IOPS
- Average Power Consumption (system level):
- 6 W (Average), 9 W (Maximum)
- Power consumption (Idle): Max. 30 mW
- Allowable Voltage: 3.3 V ± 5 % Allowable voltage
- Reliability (MTBF): 1.5 Million Hours Reliability (MTBF)
- Operating Temperature: 0 - 70 ℃ Operating Temperature
- Shock: 1,500 G & 0.5 ms (Half sine)
Software
- Management SW: Magician Software for SSD management
