Description:
USB Video Output
Sleek and intelligent design
Plug & Play USB2.0 Connectivity
Crystal clear HD1080P image quality
Accurate,smooth and silent PTZ Movement
Preset: 10 via IR remote setting (255 via RS232)Wide field of view with no video distortion
1/3 inch high quality, 2.1MP (16:9) CMOS sensor
Superior quality with Full Glass Lens Material
Support ceiling mount, wall mount and tripod mount (Reverse mountable)
2D and 3D NR for best video quality in different lighting conditions
Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
Compatible with most leading video conferencing software and platform
Features:
Model: UHD3U
Sensor: 1/2.9″HD color CMOS
Effective pixel: 2.1 mega pixel
Video signals: 1080p-30/25, 720p-30/25
Zoom: 3x optical zoom
Lens: f=3.35-10.05mm
Aperture: F1.7～F3.0
Horizontal angle: 99.6°(W)-30.6°(T)
Vertial angle: 53.0°(W)-17.2°(T)
Diagonal angle: 129.2°(W)-37.6°(T)
Video encoding format: MJPEG, YUY2 MJPEG/YUY2/H.264
Video resolution: 4K(3840*2160) etc 1080P (1920 *1080) etc
Siginal standard: NTSC/PAL
Preset position: User can set up to 64 presets (IR remote 10 presets)
Control terminal: RS-232,RS485
Shutter : 1/30s～1/10000s, auto
Baud rate: 38400/9600bps
Control protocol: VISCA, PELCO-D, PELCO-P(RS-232, RS485)
USB protocol: UVC1.1
Minimal Illumination: 0.1Lux
SNR: ≥50dB
Horizontal rotation: 350°（±175°）0.1°/s～100°/s
Vertical rotation: 180°（±90°）0.1°/s～80°s
Power supply: DC 12V/2A
Power consumption: 12W
Work temperature: 0°~+50°
Work humidity: 0~95% RH
Product size: 212*160*172mm/260*217*197mm (before / after packing)
Product weight: 1.25kg/2.05kg(net / gross weight)
