Description
The Tenveo TEVO NV20U is a professional-grade PTZ (Pan-Tilt-Zoom) video conferencing camera designed for modern meeting rooms, lecture halls, and hybrid collaboration environments. It features a powerful 20× optical zoom lens paired with a high-quality full HD 1080p resolution output, delivering clear, detailed video suitable for larger spaces where subtle framing and distant subjects need to be captured crisply. The camera uses a high-performance CMOS image sensor to produce smooth, vibrant video and supports automatic 2D/3D noise reduction to maintain image quality across varying lighting conditions. With its precision PTZ mechanics, it offers wide pan and tilt ranges and programmable preset positions that let you quickly recall preferred camera angles during sessions. Connectivity is plug-and-play via USB, making it broadly compatible with popular video conferencing platforms like Zoom, Teams, and Skype, while support for VISCA and Pelco control protocols enables remote control over RS-232/RS-485 interfaces. Built to be versatile, this Tenveo model also supports multiple mounting options—desktop, tripod, wall, or ceiling—so it can be installed in virtually any professional space with ease
The Tenveo 4K NDI PTZ camera is a professional-grade pan-tilt-zoom camera designed for video conferencing, live streaming, and hybrid production setups. It features a 20× optical zoom lens with 4K UHD capture for sharp, detailed video, plus support for multiple output interfaces like USB 3.0, HDMI, and Ethernet/NDI for flexible connectivity in both networked and local workflows. The built-in NDI support enables low-latency IP-based streaming and control across standard networks, making it suitable for multi-camera productions without needing traditional capture hardware. Some variants also include AI-based auto-tracking and advanced video encoding options, helping keep subjects framed smoothly during events or broadcasts while integrating easily with popular conferencing and streaming platforms.
Key Features
Standard 4K
● 20x optical zoom with sleek and intelligent design
● Smart AI auto tracking with auto framing and presenter tracking
● Plug-and-play USB 3.0, HDMI output, and RJ45 port
● Crystal clear 4K@30fps image quality
● Accurate, smooth, and silent PTZ movement
● 10 presets via IR remote (255 via RS232)
● Full glass lens for superior quality
● 62° wide field of view with no distortion
● 1/2.8-inch 8.29MP CMOS sensor
● Supports ceiling, wall, and tripod mounting
● 2D and 3D noise reduction for various lighting
● Supports VISCA, Pelco-P, and Pelco-D protocols with RS232/RS485 control
● Compatible with most video conferencing software and platforms
4K with NDI|HX2
● 20x optical zoom
● Sleek and intelligent design
● Smart AI Auto Tracking with Auto framing and Presenter Tracking
● Plug & Play USB3.0 Connectivity, HDMI Output and RJ45 Port
● Crystal clear 4K@30fps image quality
● Accurate, smooth and silent PTZ Movement
● Preset: 10 via IR remote setting (255 via RS232)
● Superior quality with Full Glass Lens Material
● 62° wide field of view with no video distortion
● 1/2.8 inch high quality, 8.29 MEGA PIXEL (16:9) CMOS sensor
● Support ceiling mount, wall mount and tripod mount (Reverse mountable)
● 2D and 3D NR for best video quality in different lighting conditions
● Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
● Compatible with most leading video conferencing software and platform
Specification
Standard 4K
● Brand: Tenveo
● Model: NV20U-4K
● Image Sensor: 1/2.8"" SONY CMOS, 8.29MP
● Optical Zoom: 20x, Digital Zoom: 8x
● Lens Aperture: F1.7-F3.7, Focal Length: 4.95mm~99mm
● Video Format: HDMI 4K@30fps, USB3.0 H.264/H.265/MJPG/YUY2
● AI Support: Single/Multi-Person Tracking, Auto/Manual Focus
● Pan/Tilt Rotation: 350° / 180°, Presets: 10 Remote, 255 Serial
● Network Protocols: RTSP, RTMP, VISCA over IP, ONVIF, SRT
● I/O Interfaces: USB3.0, HDMI, RJ45 (PoE), RS232, RS485
● Operating Conditions: 0°C~40°C, 20%-80% RH, Power: DC12V, 24W Max
● Dimensions/Weight: 171x163x173mm, Net 1.5kg / Gross 2.7kg
4K with NDI|HX2
● Brand: Tenveo
● Model: NV20U-4K-NDI
● Image Sensor: 1/2.8"" SONY CMOS, 8.29MP
● Optical Zoom: 20x, Digital Zoom: 8x, Zoom Speed: 1~8
● Lens Aperture: F1.7-F3.7, Focal Length: 4.95mm~99mm
● Video Format: HDMI 4K@30fps, USB3.0 H.264/H.265/MJPG/YUY2
● AI Support: Single/Multi-Person Tracking, Auto/Manual Focus
● Pan/Tilt Rotation: 350° / 180°, Presets: 10 Remote, 255 Serial
● Network Protocols: RTSP, RTMP, VISCA over IP, ONVIF, SRT, NDI|HX2
● I/O Interfaces: USB3.0, HDMI, RJ45 (PoE), RS232, RS485
● Operating Conditions: 0°C~40°C, 20%-80% RH, Power: DC12V, 24W Max
● Dimensions/Weight: 171x163x173mm, Net 1.5kg / Gross 2.7kg
What's in the box?
● 1 x PTZ Video Camera
● 1 x Wall Mount
● 1 x AC Adapter
● 1 x Remote
● 1 x USB 3.0 Cable
● Manual
● Screws
