TEVO UV20A
4K PTZ Camera
Features:
- 20x Optical zoom
- USB3.0 HDMI 3gG-SDI RJ45 Video Output
- 1080P Video Image
- Preset: 10 via IR remote setting (255 via RS232)
- 61° Wide field of view with no video distortion
- Sony IMX327 1/2.8"" CMOS, 2.07 mega pixel
- Support H.264, H.265, MJPG, YUY2 Video Compression Format
- Support RTSP, RTMP, ONVIF, GB/T28181 Network Protocol, Support VISCA Over IP and POE Support
- 2D and 3D NR for best video quality in different lighting conditions
- Support Visca, Pelco-P, and Pelco-D protocol, RS232/RS485 Camera Control
- Compatible with most leading video conferencing software: Zoom, Skype, Webex. Teams, Google meet and LIve Streaming software: vMix, OBS, Facebook Live, YouTube Live, Vimeo Live, Twitch, Wirecast, Livestream Studio, MimoLive, Tricaster, etc.
- Utilizing belt drive technology the PTZ is ultra-quiet and fast, while being very smooth
Specifications:
- Model No.: UV20A
- Image Sensor: Sony IMX327 1/2.8"" CMOS
- Effective Pixels: 2.07MP
- Optical Zoom: 20x zoomLens: f=3.42-40.02mm
- Aperture: F1.6-3.5
- Horizontal Angle: 55.8°(W)-3.2°(T)
- Vertical Angle: 32.2°(W)-1.8°(T)
- Diagonal Angle: 61°(W)-3.64°(T)
- Video Format: 1080P@60/59.94/50/30/29.97/25fps,720P@60/59.94/50/30
- Video Encoding Format: H.264, H.265, MJPG, YUY2
- Backlight Compensation: Support
- SNR: >50dB
- Focus: Auto / Manual
- Digital Noise Reduction: 2D & 3D Noise Reduction
- Exposure: Auto / Manual
- Video Interfaces: HDMI, USB3.0, RJ45, SDI
- Video Compression Format: H.264, H.265, MJPG, YUY2
- LAN: 10M/100M/1000M adaptive Ethernet port; Support POE IEEE802.3at
- Network Protocol: RTSP, RTMP, ONVIF, GB28181; Support VISCA Over IP
- Control Protocol: VISCA/Pelco-D/Pelco-P; Baud Rate: 9600/4800/38400/2400
- Control Interface: RS232, RS485,USB3.0 TYPE-B(UVC1.1), RJ45
PTZ Parameter
- Pan/Tilt Rotation: ±175°, -90°～+90°
- Pan Control Speed: 0.1 -80°/sec
- Tilt Control Speed: 0.1 -60°/sec
- Preset Number: User can set up to 255 presets (10 presets by IR remote)
General Parameter
- Operation Systems: Windows 7, Windows 8.1, Windows 10, Windows 11; Android, Mac OS™ 10.10 or higher, Linux (Required to support UVC.)
- Input Voltage: DC 12V
- Input Current: 2.0A (Max.)
- Power Consumption: 13W (Max.)
- Store Temperature: -20°C to 60°C
- Store Humidity: 20%～90% RH
- Working Temperature: 0℃ to 40°C
- Working Humidity: 20%～80% RH
