Archer TX20E
AX1800 Wi-Fi 6 Bluetooth 5.2 PCIe Adapter
-
Unrivalled Wi-Fi 6 Speed—Breaks the gigabit barrier with speed up to 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
-
Wider Signal Coverage— Connect to your Wi-Fi in more parts of your home with two external high-gain antennas ensuring greater coverage and enhanced stability
-
Bluetooth 5.2—The latest Bluetooth technology achieves 2× Faster Speed and 4× Broader Coverage than BT 4.2
-
Improved Security—The latest security enhancements WPA3 provides enhanced protection in personal password safety
-
Backward Compatibility – Full support for 802.11ax/ac/a/b/g/n standards
Features:
-
Antenna Type
Two High-Gain Dual Band Antennas
-
Chipset
Realtek Wi-Fi 6 Chipset
-
Wireless Standards
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/g/b 2.4 GHz
Bluetooth 5.2
-
WLAN Signal Rate
5 GHz
11ax: Up to 1201 Mbps(dynamic)
11ac: Up to 867 Mbps(dynamic)
11n: Up to 300 Mbps(dynamic)
11a: Up to 54 Mbps(dynamic)
2.4 GHz
11ax: Up to 574 Mbps(dynamic)
11n: Up to 300 Mbps(dynamic)
11g: Up to 54 Mbps(dynamic)
11b: Up to 11 Mbps(dynamic)
-
WLAN Reception Sensitivity
5 GHz :
11ax HE80: -57.0dBm
11ax HE40: -60.0dBm
11ax HE20: -63.0dBm
11ac VHT80: -59.5dBm
11ac VHT40: -62.5dBm
11ac VHT20: -67.5dBm
11n HT40: -69.5dBm
11n HT20: -72.5dBm
11a 54Mbps: -74.0dBm
11a 6Mbps: -94.5dBm
2.4GHz :
11ax HE40: -60.0dBm
11ax HE20: -63.0dBm
11n HT40: -69.5dBm
11n HT20: -72.5dBm
11g 54Mbps: -74.0dBm
11b 11Mbps: -88.0dBm
-
WLAN Transmit Power
5 GHz : 27dBm(FCC) / 23dBm(CE) (EIRP)
2.4 GHz : 25dBm(FCC) / 20dBm(CE) (EIRP)
-
WLAN Modes
Infrastructure mode
-
Wireless Security
Support 64/128 bit WEP,
WPA/WAP2/WPA3, WPA-PSK/WPA2-PSK, 802.1x
-
Modulation Technology
DBPSK, DQPSK, CCK, OFDM,
16-QAM, 64-QAM, 256-QAM, 1024QAM
