Description:
- Connect the TP-Link TL-SM311LM Mini-GBIC Multi-Mode Module to a compatible switch to extend data transfer distances. This module is compatible with all SFP ports and works with a multi-mode fiber connection using the IEEE 802.3z protocol to transfer data at up to 1.25 Gb/s. Featuring a 850nm wave length, the TL-SM311LM has a transmission range of up to 1804.46' using 50/125 µm multi-mode fiber cables and a 902.23' range over 62.5/125µm multi-mode cables.
Key Features:
- 1 x LC/UPC-Type Mini-GBIC Port
- Up to 1.25 Gb/s Throughput
- 802.3z Fiber Channel
- Supports Multi-Mode Fiber Connection
- Up to 1804.46' Cable Distance
- 850nm Wave Length
Other Details:
- Multi-mode MiniGBIC module
- Compatible with all SFP ports on TP-Link product including JetStream switches, and media converter MC220L.
- Work with MC200CM with a multi-mode fiber connection
- Up to 550m range with 50/125 μm multi-mode fiber
- Up to 275m range with 62.5/125 μm multi-mode fiber
Specifications:
- Brand: TP-Link
- Model(s): TL-SM311LM
- Type: Data Transfer Extender Module
- Form Factor: SFP
- Ethernet Standards: IEEE 802.3z
- Ports: 1 x Duplex LC/PC
- Wavelength: 850 nm
- Protocol: CSMA/CD
- Maximum Networking Distance: 1804.5' / 550 m
- Maximum Data Rate: 1.25 Gb/s
- Mode: Multi-Mode
What's in the Box:
- MiniGBIC Module
- User Manual
