Description:
This unit consist of Optics, Temperature Sensor Signal amplifier, Processing circuit and LCD Display. The Optics collected the infrared energy emitted by object and focus onto the Sensor. Then the sensor translates the energy into an electricity signal. This signal will be turned out to be digital shown on the LCD after the signal amplifier and processing circuit.
Features:
- Positioning laser
- Backlit screen
- Data retention
- High and low temperature alarm
- Max/Min display
- Low battery reminder
- Self-calibration
- ℃/℉ conversion
Specifications:
- LCD: Colored LCD
- Temperature range: --50°C~400°C, -50°C~600°C, -50°C~800°C, -50°C~950°C
- Temperature measurement error: -50~0℃ ( -58 ~32℉):±3℃ (±5℉ ), 0 ~600℃ (32 ~1112℉ ):±1.5% rdg, or±1.5℃(±2.7℉ )Take the bigger value
- Rrepeatability: 1% rdg or 1℃Take the bigger value
- Reponse time: 0.5s, 95% Response
- Emissivity: 0.10~1.00 Adjustable(preset as 0.95)
- D:S: 12:1
- Response wavelength: 5μm~14μm
- No operation shutdown: About 7 seconds
- Batteries: 1.5V AAA battery*2(No.7 battery)
- Low power indicator: Low power indicator for power below 2.5V
- Overload indicator: “Hi”/“Lo” displayed on LCD
- Exceed upper/lower limits of work environment: “AH”/“AL” displayed on LCD
- Working environment temperature: 0℃~40℃(32℉~104℉)
- Storage temperature: -10℃~60℃(14℉~140℉)
