Yamaha MG06X 6-Channel Audio Console Mixer with 6 Built-in SPX Effects, 2-Band EQ Equalizer, D-PRE Mic Preamps, XLR and 6.35mm AUX I/O Connectivity and 48V Switchable Phantom Power for Studio Production and Recording | MG06X

Road Tough. Studio Ready.
● For more than a century, Yamaha has been building a legacy of superior craftsmanship and innovation exemplified in all of our products, from an unrivalled catalog of world-class musical instruments to touring-grade professional audio. Now in its third incarnation, the MG Series embodies this pursuit of design excellence, and incorporates some of the same technologies developed for use in high-end professional consoles, including studio-quality preamps, powerful digital processing, and a rugged, reliable construction.

● With an intuitive, easy-to-use interface, the MG Series boasts an extensive lineup of compact mixing consoles with models ranging from six to twenty channels, suitable for a diverse range of users and applications. For installed, recording, or live music settings, the solid construction and flexible design of these consoles lets you shape your sound with confidence, continually delivering peak performance and a level of sound quality and reliability unrivalled in its class

MG06X (with FX)
● 6-Channel Mixing Console
● Max. 2 Mic / 6 Line Inputs (2 mono + 2 stereo)
● 1 Stereo Bus
● “D-PRE” mic preamps with an inverted Darlington circuit
● High-grade effects: SPX with 6 programs
● XLR balanced outputs
● PAD switch on mono inputs
● +48V phantom power
● Metal chassis
● Dimensions(W×H×D): 149 mm x 62 mm x 202 mm (5.9"x 2.4"x 7.9")
● Net Weight: 0.9 kg (1.98 lbs.)

Other Details:
► D-PRE (Discrete Class-A Mic Preamps)
► High Quality Sound Op-amp
► Switchable Phantom Power and PAD Switch
► 1-Knob Compressors
► EQ and High-Pass Filters
► AUX / Effect Sends / Group
► LED Level Metering
► Built-in SPX Digital Effects
► Metal Chassis
► Internal Universal Power Supply

Specifications:
● Brand: Yamaha
● Model MG06
● Item Type: 6-Channel Audio Mixer Console
● Input Channels: 2x XLR-1/4" Combo (Mic/Line), 2x 1/4" / 6.3mm Stereo (Line)
● Phantom Power: +48 V Switchable, Channels 1, 2
● Power Consumption: 12W
● Output Channels:
● 2x XLR Stereo
● 2x 1/4" / 6.3mm Stereo
● 1x 1/4" / 6.3mm Headphone
●  Bus: 1x 1/4" / 6.3mm Stereo
●  Pad: 26 dB (Mono Channels)
● HPF: 80 Hz, 12 dB/Oct (Mono Channels)
●  Equalizer:EQ High (Mono Channels) Gain: ±15 dB, Frequency: 10 kHz Shelving / EQ Low (Mono Channels) Gain: ±15 dB, Frequency: 100 Hz Shelving
● LED: LED Turns On When Post EQ Signal Reaches 3 dB Below Clipping
● Level Metering: 2 x 7-Segment LED Meter (Peak, +6, +3, 0, -3, -10, -20 dB)
● Total Harmonic Distortion: 0.01% @ +8 dBu (20 Hz to 20 kHz), Gain Knob: Min, 0.003% @ +18 dBu (1 kHz), Gain Knob: Min
● Frequency Response: 20 Hz to 20 kHz ±0.5 dB, Refer to the Nominal Output Level @ 1 kHz, Gain Knob: Min
● Equivalent Input Noise: -128 dBu (Mono Input Channel, Rs: 150 Ohms, Gain Knob: Max)
● Residual Output Noise: -102 dBu (Stereo Out, Stereo Level Knob: Min)
● Crosstalk: -88 dB
● Power Requirements:PA-130 (12 VDC / 1 A), 120 VAC, 60 Hz / MU18 (12 VDC / 1.5 A), 100-240 VAC, 50/60 Hz Or Equivalent Recommended by Yamaha
