Features
- Four mic inputs with XLR connectors
- Four headphone outputs with individual volume control
- Gain control knobs and mute buttons for each input
- Phantom power for all XLR inputs
- Automatically prevent feedback from call audio using the Mix-Minus function
- Easily connect your phone using the TRRS connection
- Trigger sound effects using four assignable Sound Pads with 11preset sounds
- All input sources can be recorded on separate tracks
- 16-bit /44.1kHz audio WAV
- Records directly to SD, SDHC and SDXC cards up to 512 GB
- 2-input, 2-output USB audio interface
- Class-compliant mode for iOS compatibility
- Up to four hours of use with just two AA batteries or a USB power supply
Specifications:
INPUTS & OUTPUTS:
- NUMBER OF INPUT CHANNELS : 4 (mono/stereo)
- NUMBER OF OUTPUT CHANNELS: 1 (headphone x 4)
CONNECTORS:
- MIC: XLR jacks (2: HOT)
- SMARTPHONE CONNECTION JACK: TRRS mini jack (4 contacts, TIP: L, RING1: R,RING2: GND, SLEEVE: MIC)
- USB: USB Type-C (audio interface and mass storage functions)
- Note: Use a USB cable that supports data transfer. USB bus power is supported.
- DC 5 V: USB Type-C (for power supply)
- HEADPHONES: 3.5 mm stereo mini
- PHANTOM POWER: +48 V
- AUDIO INTERFACE 44.1 kHz, 16-bit, 2-in/2-out
